WHY ARE WHEEL HUB ASSEMBLIES IMPORTANT?

Wheel hub assemblies connect your vehicle’s wheels and rotor to the caliper and allow smooth rotation. They are typically attached to the steering knuckle or rear axle flange/spindle, and depending on the application, they may feature ball or tapered rolling elements.



Designed to minimize friction and support the wheel load , wheel hub assemblies reduce the resistance of your wheels when in contact with the road. They also control wheel positioning, which determines several performance factors, including tire wear, braking control, vehicle stability in both straight lines and turns, and overall vehicle handling.

Wheel hub assemblies may be considered an important part of a vehicle’s ABS, TCS and ESC systems. Based on continuous inputs from the integrated ABS sensor, these control systems ensure safe operation.

Requirements for wheel hub assemblies include:

Precision machining of raceway and flanges

Premium rolling elements (optimized size, finish and material)

High-quality lubricating grease

Durable seal construction and material

Accurate ABS sensor signal and plug

Exact orbital roll forming

Designed as pre-assembled units, wheel hub assemblies feature precision machined rolling elements, seals, mounting flanges and commonly, integrated ABS sensors. They are pre-adjusted and pre-set, so they require no maintenance.

Automotive Applications Use Two Types of Rolling Elements

Ball Bearings/Sphere Shaped Rolling Elements

Double row angular contact wheel bearings work best in light- to medium-duty applications. They have a good capacity to handle radial and axial load, and their compact design saves on weight.

  • Tapered/Cone Shaped Rolling Elements:

    Used for larger vehicles and heavy-duty applications, tapered rolling elements have an excellent capacity to handle radial and axial load. They feature a cup and cone design.

  • Cup and Cone Design:

    This design is used in pairs on front or rear non-driven wheels. Setting the preload is mandatory, and because they don’t have an integrated seal, maintenance is required. Repack with grease periodically.

Generations

Although most OEM manufacturers have moved to a unitized Generation 3 design, the vehicle aftermarket has the following versions available.

Third generation wheel hub assemblies can be used on driven or non-driven axles.

Use compact double row ball bearings or tapered rollers which cannot be disassembled

Come as a complete unit with two flanges for securing to the knuckle and brake rotor/wheel

Pre-set bearing clearance

Orbital or roll formed

Pre-greased and maintenance free

May feature an ABS encoder ring

Second generation wheel hub assemblies can be used on driven or non-driven axles.

Use compact double row ball bearings which cannot be disassembled

Feature an additional hub or mounting flange with a rotating inner or outer ring

Pre-greased and maintenance free

May feature an ABS encoder ring

First generation wheel bearings can be used on front and rear axles.

Found on many passenger and light commercial vehicles

Compact double row design which cannot be disassembled

Pre-greased and maintenance free

May feature an ABS encoder ring

MEVOTECH TTX WHEEL HUB ASSEMBLIES

  • Engineered Internals
    Engineered Internals

    Precision-engineered higher grade rolling elements and optimized geometry to minimize rolling resistance and maximize load distribution. ​ Components are matched together for exact mating fitment – meaning quiet performance and longer service life.

  • Generation 3 Orbital Roll Forming
    Generation 3 Orbital Roll Forming

    Roll forming locks internal components for a set preload right out of the box. No adjustment is required over service life. Increased assembly stiffness reduces potential vibration and improves part life.

  • Advanced Sealing
    Advanced Sealing

    Low-friction, heavy-duty Advanced Quantum Sealing System with a multi-lip profile that provides several layers of defense to keep contaminants out and vital grease in.

  • NanoCeramic Lubricant Technology
    NanoCeramic Lubricant Technology

    NanoCeramic lubricant withstands extreme temperatures, resists corrosion and washout, and retains viscosity. ​ ​Particles also act as microscopic bearings reducing friction, filling and smoothing out raceways and rolling elements.

  • Uninterrupted Wheel Speed Signal
    Uninterrupted Wheel Speed Signal

    A molded, thicker and abrasion-resistant cord guards against perforation and contaminants at both the sensor and plug ends to ensure a faultless signal for ABS, TCS and other vehicle safety systems. The sensors match to the original for type and output characteristics, meaning no interruption in this service.

  • Repel-TEK Anti-Corrosion
    Repel-TEK Anti-Corrosion

    Repel-TEK™ anti-corrosion coating is applied to every surface, including studs and hardware, to prevent buildup and contaminant intrusion. This also makes removing associated components easier, like swapping wheels, replacing a CV shaft or a brake rotor.

  • Everything in the Box for a Complete Job
    Everything in the Box for a Complete Job

    Where applicable, fastening hardware, fastening torque specifications and vehicle ABS signal type are included for a quick and complete repair.

THE MEVOTECH EDGE

What makes our wheel hub assemblies so great? Mevotech gives technicians the edge, by innovating every chassis component. Our engineers focus on making our parts faster and easier to install, and we engineer them to provide a longer service life. Employing punishing durability testing, we validate every new design to ensure you get performance you can trust.

TTX Hubs

To make your installations faster, easier and protect surrounding components, we include handy Labor Savers in the box

  • Engineered Internals

    Precision-engineered higher grade rolling elements and optimized geometry to minimize rolling resistance and maximize load distribution. ​ Components are matched together for exact mating fitment – meaning quiet performance and longer service life.

  • Engineered Internals
    Generation 3 Orbital Roll Forming

    Roll forming locks internal components for a set preload right out of the box. No adjustment is required over service life. Increased assembly stiffness reduces potential vibration and improves part life.

  • Generation 3 Orbital Roll Forming
    Advanced Sealing

    Low-friction, heavy-duty Advanced Quantum Sealing System with a multi-lip profile that provides several layers of defense to keep contaminants out and vital grease in.

  • Advanced Sealing
    NanoCeramic Lubricant Technology

    NanoCeramic lubricant withstands extreme temperatures, resists corrosion and washout, and retains viscosity. ​ ​Particles also act as microscopic bearings reducing friction, filling and smoothing out raceways and rolling elements.

  • NanoCeramic Lubricant Technology
    Uninterrupted Wheel Speed Signal

    A molded, thicker and abrasion-resistant cord guards against perforation and contaminants at both the sensor and plug ends to ensure a faultless signal for ABS, TCS and other vehicle safety systems. The sensors match to the original for type and output characteristics, meaning no interruption in this service.

  • Uninterrupted Wheel Speed Signal
    Repel-TEK Anti-Corrosion

    Repel-TEK™ anti-corrosion coating is applied to every surface, including studs and hardware, to prevent buildup and contaminant intrusion. This also makes removing associated components easier, like swapping wheels, replacing a CV shaft or a brake rotor.

  • Repel-TEK Anti-Corrosion
    Everything in the Box for a Complete Job

    Where applicable, fastening hardware, fastening torque specifications and vehicle ABS signal type are included for a quick and complete repair.

  • Everything in the Box for a Complete Job
    Knurled Housing

    Precision engineered ridges for tighter grip between connecting components.
